Procon - Məhsul - Honeywell PM45

Təsvir

Features

Accurate & reliable high speed printing
Broad connectivity options

2D Barcodes

All major 2D barcodes

Applications & Compatibility

Compatible Software

BarTender
Nicelabel
Operational Intelligence
SOTI Connect
Teklynx Labelview

Application

Food and beverage
Healthcare
Warehouse and distribution center

Technical Specifications

Compatible Drivers

CUPS Driver for Linux
Certified Device Types for SAP
InterDriver Windows

Resolutions

203 dpi
300 dpi
406 dpi
600 dpi

Print Speeds

50-350mm/s (2-14 ips)

Print Method

Direct Thermal
Thermal Transfer

Linear Barcodes

All major 1D barcodes

Downloadable Font Type

Bitmap Font
OpenType Font (TrueType based)
TrueType Font

Printer Media Type

Label
Linered
RFID
Tag

Wireless Communication

IEEE 802.11 a/b/g/n/ac
TLS, PEAP, TTLS, PWD, LEAP, FAST
WWAN Radio
Wi-Fi Certified

Printer Command Language

C# Smart Printing
DPL
Direct Protocol (DP)
Fingerprint (FP)
Intermec Printer Language (IPL)
PDF
XML-enabled for SAP AII and Oracle WMS
ZSim2 (ZPL-II)

RAM Memory

256 MB

Memory

External Multi-GB USB memory device (FAT16/FAT32)

Image File Format

Flash Memory

512 MB

Printer Connection Interface

Applicator Interface
Industrial interface
Parallel Interface (IEEE 1284)
RFID
RS-232
USB 2.0 Host (x2 PM45, x1 PM45C)

Operating Frequency

50 - 60 Hz

RFID Specifications

RFID

Platform

Honeywell Printer Edge

Network Specifications

Ethernet 10/100 Mbps

Font Engine

Monotype Font Engine
WTLE for Global Language Support

Bluetooth Specifications

Bluetooth Classic 5.0

Dimensions & Weight

Overall Dimensions

PM45: L x H x W: 483 mm x 295mm x 284 mm (19.0 in x 11.11.6 in x 11.2 in)
PM45c with Mega Door: L x H x W: 500 mm x 245 mm x 253 mm (19.7 in x 9.6 in x 10.0 in)
PM45c: L x H x W: 432 mm x 181 mm x 253 mm (17.0 in x 7.1 in x 10.0 in)

Maximum Ribbon Length

450 m (1476 ft)

Weight

PM45: 13.2 kg (29.1lbs)

Maximum Media Roll Diameter

213 mm (8.38 in)

Electrical Specifications

Operating Voltage

AC Voltage: 100 to 240V AC, 50 to 60 Hz

Operating Characteristics

Operating Temperature

+41°F to +104°F
+5°C to +40°C

Operating Humidity

20 - 85 % non-condensing

Storage Temperature

-20°C to +70°C (-4°F to +152°F)

Storage Humidity

5 - 90 % non-condensing

Overview

Warranty Duration

One year factory warranty

Others

Print Width

4 inch

Print Volume

Up to 10,000
Up to 5,000

Print Technology

Direct Thermal
Thermal Transfer

Honeywell PM45
